Straw Pellet Production Line Manufacturer in China

It is strongly recommended to contact a professional manufacturer when preparing to build your new straw pellet production line. In addition to bringing you the guarantee of equipment quality, we can also give you a professional straw pellet plant layout according to your site.

  • Corn stalks, wheat stalks, and even sugar cane stalks, etc., agricultural waste can be used as raw materials for pellet production
  • RICHI is responsible for the design, equipment production, transportation and installation of the entire pellet line
  • Factory Direct Sales – 100% Competitive Factory Price

RICHI Machinery is the 27+ years of experience straw pellet production manufacturer in China.

    Straw Pellet Production Line

    • Your Straw Pellet Production Line with Higher Capacity
    • Higher Density and Compressive Strength for Straw Pellets
    • Waste Straw recycle to Protect Environment
    • Different Configurations <suitable for different budgets> Are Available
    • Competitive Factory Price and Best Quality in China

    BRAND

    RICHI Machinery

    MODEL

    MZLH Series

    CAPACITY

    0.5-40TPH<Can Be Customized>

    POWER

    According to the whole system

    Necessary Equipment For Complete Straw Pellet Production Line

    Crushing Machine For Sale

    • RICHI Straw Crushing Machine for Crushing Materials in Straw Pellet Production Line
    • Model: RI-600/RI-800/RI-1000/RI-1200
    • Capacity: 0.8-1T/H, 2-4T/H, 4-6T/H, 6-8T/H
    • Raw Materials:
    • Corn stalks, wheat stalks, and even sugar cane stalks, etc., agricultural waste can be used as raw materials for pellet production
    • RICHI Straw Dryer Machine for Drying Materials in Straw Pellet Production Line
    • Model: ф1200*120000, ф1500*150000, ф1800*180000, ф2400*100000, ф2400*100000*3
    • Application: Suitable for a large amount of low-temperature continuous drying materials, such as Corn stalks, wheat stalks, and even sugar cane stalks, etc. agricultural waste.

    The MZLH series straw pellet making machine has a larger ring die and pelletizing chamber to ensure high-efficiency straw pellet production. In order to adapt to lighter raw materials, we have added a forced feeder.

    • Power: 30-300KW
    • Capacity: 0.5-10T/H
    • Pellet Size: 6-12mm
    • Model: SKLN11*11, SKLN14*14, SKLN17*17, SKLN20*20, SKLN24*24
    • Capacity: 1.5-2T/H, 3-5T/H, 5-8T/H, 9-12T/H, 13-18T/H
    • Application: Cooling of high temperature pellet after pelleting
    • Main Application Scenario: straw pellet production line post-processing section
    • Brand Name: RICHI Straw Pellet Packing Machine
    • Model: DCS-C50/D, DCS-A50/D, DCS-B50/D, DCS-B50/S, DCS-A50/Y
    • Application: Mainly used in pellet production lines. As the last step of the equipment, the finished product is packaged for storage and transportation.
    • Main Application Scenario: finished product packaging section of straw pellet production line

    Welcome to Visit RICHI Machinery Factory

    We welcome you to visit us, to discuss straw pellet production line with us.

    Complete Pellet Productiion Line

    The key equipment of complete straw pellet production line is crusher, dryer, straw pellet machine, pellet cooling machine, straw pellet packing machine. Different straw pelletizing solutions are available. Leave us a message, and we will design a reasonable pellet production line for you according to the needs and budgets. Learn more cost of the complete pellet production line.

    • Civil heating and life energy use; high combustion utilization rate, easy to store
    • Biomass industrial boiler; as the main fuel of industrial boilers, it can replace coal and solve environmental pollution
    • Power generation: can be used as a fuel for thermal power generation

    3D Process Drawing Of Straw Pellet Production Line

    Our straw pellet production solutions have spread all over the world.

    Our pellet production line can process many kinds of materials

    biomass raw materials

    This complete straw pellet production line can not only process basic various straws and other agricultural wastes, but also process peanut shells, sugar cane, sawdust, coffee shells, straw, sunflower stalks, cotton stalks, tobacco waste, mustard stalks, jute waste , Bamboo, dust, tea dregs, wheat stems, palm shells, soybean shells, coconut shells, etc.

    Until now, we have established a number of pellet production lines and sold them all over the world. Our customers are located in the United States, Canada, the United Kingdom, Russia, France, Greece, Angola, South Africa, Australia, Argentina, Mexico, Chile, Peru, etc.

    If you want to build a straw pellet factory, please contact us, just tell us your raw material and output requirements, and we can customize a straw pellet production line for you.



    Video For Straw Pellet Making Machine

    Straw Pellet Production Line: Definitive Guide

    What are straw pellets used for?

    Straw pellets are fuel pellets made from crops such as corn stalks, wheat stalks, and rice straws, which are compressed and molded through a straw pellet production line.

    Pellets are produced by squeezing raw materials such as wood chips and straws by pressing rollers and ring molds at room temperature. The density of the raw material is generally about 1100 kg/m3, and the density of the formed particles is greater than 1100 kg/m3, which is very convenient for transportation and storage. At the same time, its fuel performance is greatly improved.

    What can be pelletized?

    The straw pellet production line can pelletize crop waste such as corn stalks, wheat stalks, and rice straws.

    In addition to agricultural wastes, forest wastes, urban wastes, and various biomass wastes can basically be pelletized through pellet production lines.

    How do you use straw pellets?

    • Civil heating and domestic energy: high combustion utilization rate, easy to store
    • Biomass industrial boiler: As the main fuel of industrial boilers, it can replace coal and solve environmental pollution.
    • Power generation: can be used as a fuel for thermal power generation
    • For horse bedding

    How to make straw pellets?

    1. Preparation: various crop straws or other biomass raw materials
    2. Processing: use a straw pulverizer to pulverize crop stalks to powder below 3-5mm
    3. Drying: use a drum dryer to reduce the moisture content of straw powder
    4. Pelleting: a professional straw pellet machine presses straw powder into pellets
    5. Pellet cooling: The pellet cooler can reduce the high temperature straw pellets to below room temperature
    6. Packing system: The fully automatic packing system fully saves human resources, and the packed straw pellets are more convenient for storage and transportation

    The above equipment is the main production equipment of the entire straw pellet production line. In addition to these, it will also involve conveying systems, wind transportation systems, storage systems, and electronic control systems (PLC systems). Contact us to customize the straw pellet production line or learn more about other biomass pellet solutions.
